FMP54 Guided Level-Radar Level And Interface Measurement In Liquids Levelflex

Product Description

• Measuring range up to 45 m (148 ft)
• Process connection starting 3/4 inch thread or flange
• Temperature range: -196 to +450 deg C (-321 to +842 deg F)
• Pressure range: -1 to 400 bar (-14.5 to 5 800 psi)
• The following interfaces are available for system integration:
• HART with 4...20 mA analog
• PROFIBUS PA (Profile 3.02)
• FOUNDATION Fieldbus
• Used for level monitoring (MIN, MAX, range) up to SIL 2 (single device) or SIL 3 (redundancy, even if homogeneous), independently assessed by TUV as per IEC 61508
• Rod, rope or coax probe
• Process connection: Starting 3/4" thread, flange or process connections for hygiene requirements (Tri-Clamp, 11851)
• Process temperature: -196 to +450 deg C (-320 to +842 deg F)
• Process pressure: -1 to +400 bar (-14.5 to +5800 psi)
• Maximum measuring range: Rod 10 m (33 ft) rope 45 m (148 ft) coax 6 m (20 ft)
• Accuracy: -/+2 mm (-/+ 0.08 in)
• International explosion protection certificates WHG marine approval steam boiler approval; EN10204-3.1
• Linearity protocol (3-point, 5-point)
