NBB15-30GM50-WO Inductive Sensor

Connection type

cable PVC , 2 m

Degree of protection

IP67

Housing material

brass, nickel-plated

Installation

quasi flush

Output polarity

AC

Output type

Two-wire

Rated operating distance

15 mm

Switching Function

Normally closed (NC)

Model Name/Number

NBB15-30GM50-WO

Switching function

Normally closed (NC)

Output type

Two-wire

Rated operating distance

15 mm

Installation

quasi flush

Output polarity

AC

Assured operating distance

0 ... 12.15 mm

Actual operating distance

13.5 ... 16.5 mm

Reduction factor rAl

0.33

Reduction factor rCu

0.28

Reduction factor r304

0.81

Output type

2-wire

Operating voltage

UB

20 ... 253 V

Switching frequency

f

0 ... 20 Hz

Hysteresis

H

typ. 5 %

Reverse polarity protection

reverse polarity tolerant

Voltage drop

Ud

< 5 V (IL > 50 mA); < 8 V (IL < 50 mA)

Momentary current (20 ms, 0.1 Hz)

0 ... 1600 mA

Operating current

IL

5 ... 200 mA

Off-state current

0 ... 1.7 mA

Operating voltage indicator

LED, green

Switching state indicator

LED, yellow
